From the heart of Addis Ababa, Tariku Metals has built its reputation on reliability and expertise in the industrial supply sector. We proudly supply premium materials like Super Duplex Steel Zeron 100 bars and rods to Ethiopia’s most demanding industries. Our commitment is to provide not just a product, but a dependable partnership, ensuring you have the high-performance materials needed to build and maintain robust infrastructure and equipment, all backed by our deep understanding of the local market and international quality standards.
Super Duplex Steel Zeron 100 stands out due to its impressive composition and strength. It boasts a high content of chromium, molybdenum, and nitrogen, which gives it exceptional resistance to pitting and corrosion. Mechanically, it’s incredibly tough, offering a high yield strength that often allows for lighter component designs without sacrificing durability. This material holds up beautifully under immense stress and in challenging environments, making it a go-to choice where ordinary stainless steels might fail.
| Specifications | ASTM A276, A479, ASTM A182 / ASME SA276, SA479, SA182 |
|---|---|
| Grade | Super Duplex Steel UNS S32760 F55 |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Technique | uns S32760 Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Flat bar size | Thickness: 2 -100mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Processing | Bar cutting to 650mm |
| Certificates | EN 10204 / 3.1 |
| Condition | Hardened & tempered, annealed |
| Our uns S32750 Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | Cr | Ni | Mo | C | W | Cu | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Zeron 100 | 24.0-26.0 | 6.0-8.0 | 3.0-4.0 | 0.030 Max | 0.5-1.0 | 0.50-1.0 | 0.2-0.3 | 1.00 Max | 1.0 Max | 0.03 Max | 0.01 Max | Balance |
| Grades | Alloy Zeron 100 Tensile Strength, ksi | .2% Yield Strength, ksi | % Elongation in 50mm | Hardness Max. |
|---|---|---|---|---|
| Zeron 100 | 109 | 80 | 25 | 28 HRC |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Zeron 100 | 1.4501 | S32760 |
Yes, Super Duplex Steel Zeron 100 bars can be welded. However, proper welding procedures and pre-heat treatments are essential to avoid issues like cracking and maintain its high strength and corrosion resistance.
Super Duplex Steel Zeron 100 rods are highly resistant to galvanic corrosion due to their exceptional corrosion resistance properties. However, if exposed to more active metals in a corrosive environment, some risk of galvanic corrosion may still exist.
Super Duplex Steel Zeron 100 rods are available in a range of diameters, typically from 10 mm to 300 mm, and can be customized based on specific requirements. They are commonly offered in finishes like hot-rolled, cold-rolled, and bright polished.
The uses for these robust bars and rods are extensive, particularly in environments where failure is not an option. They are essential in offshore and marine applications for parts like pump shafts and fasteners. Within chemical processing plants, they handle aggressive acids and seawater cooling systems with ease. You’ll also find them in desalination units, oil and gas extraction equipment, and pollution control scrubbers. Essentially, any project requiring long-lasting performance against corrosion and high pressure benefits greatly from the resilience of Zeron 100.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
