Tariku Metals, a well-respected manufacturer and supplier located in Addis Ababa, Ethiopia, specializes in high-quality Stainless Steel Flat Bars that are built for outstanding performance, durability, and resistance to corrosion. Crafted with cutting-edge techniques and top-notch raw materials, these flat bars adhere to international standards for precision and mechanical reliability. Renowned for their strength and versatility, Tariku Metals’ Stainless Steel Flat Bars find applications in construction, shipbuilding, automotive, and various industrial sectors. The company guarantees that each product boasts an excellent surface finish, sharp edges, and consistent quality, establishing itself as a trusted name in stainless steel supply throughout Africa and beyond.
Stainless Steel Flat Bars are generally made up of iron, 16–20% chromium, 6–12% nickel, along with trace elements like carbon, manganese, silicon, and molybdenum, depending on the specific grade. This unique blend offers remarkable resistance to corrosion, oxidation, and scaling, even under high temperatures. In terms of mechanical properties, these bars provide tensile strength ranging from 515–750 MPa, yield strength around 205–350 MPa, and impressive elongation. They are known for their high toughness, good weldability, and excellent formability. With a smooth surface finish and fine grain structure, stainless steel flat bars promise long-lasting performance in both structural and decorative uses.
| Specification | EN 10272, EN 10088-3 Grade 304/ 304L, 316/ 316L |
|---|---|
| Standard | API, ASME, SUS, DIN, EN, GB, UNS, ASTM, AISI |
| Sizes | 3mm to 800mm diameter |
| Length |
|
| Finish | Cold Drawn Turned, Bright Drawn, Polished, Rough Turned, Centreless Ground, Bright, Annealed, Smooth Turned, Peeled, Grinding, Black |
| Tolerances | H12, H11, K11, K12, H10, H8, H9, H13, K10, K9 |
| Surface Finish | 1D, HL, 8K, NO.4, 2D, NO.1, NO.3, 2B, BA |
| Production Method | Rolled / Forged |
| Characteristics |
|
| Value Added Services at Suraj Metal |
|
| Other available forms | Forging, Profiles, T-Bar, Rod, Hollow, Triangle, Channel, Threaded, Ingot, Rounds, Rectangle, Blocks, Billet, I/H, Half-Round, Angle, Precision-Ground |
| Port |
|
| Export to | Saudi Arabia, Peru, Italy, Malaysia, USA, Vietnam, Thailand, Egypt, Brazil, Ireland, Spain, Kuwait, Dubai, Singapore, Canada, Oman, Indonesia, Russia, Korea, Mexico, Canada, etc |
| Grade | Size in mm | Price List |
| AISI 304 | 12 x 3 | FOB Price: USA $10.39 |
| AISI 316L | 12 x 3 | FOB Price: USA $19.38 |
| AISI 316L | 12 x 5 | FOB Price: USA $19.95 |
| AISI 304 | 12 x 6 | FOB Price: USA $20.19 |
| AISI 304 | 20 x 3 | FOB Price: USA $17.12 |
| AISI 304 | 20 x 5 | FOB Price: USA $30.14 |
| AISI 316L | 20 x 5 | FOB Price: USA $31.91 |
| AISI 304 | 20 x 6 | FOB Price: USA $33.08 |
| AISI 316L | 20 x 6 | FOB Price: USA $39.23 |
| AISI 304 | 20 x 10 | FOB Price: USA $60.69 |
| AISI 304 | 20 x 15 | FOB Price: USA $62.17 |
| AISI 304 | 25 x 3 | FOB Price: USA $12.92 |
| AISI 316L | 25 x 3 | FOB Price: USA $23.61 |
| AISI 304 | 25 x 5 | FOB Price: USA $35.60 |
| AISI 304 | 25 x 6 | FOB Price: USA $45.42 |
| AISI 316L | 25 x 6 | FOB Price: USA $49.65 |
| AISI 304 | 25 x 8 | FOB Price: USA $60.29 |
| AISI 304 | 25 x 10 | FOB Price: USA $73.56 |
| AISI 316L | 25 x 10 | FOB Price: USA $55.08 |
| AISI 304 | 25 x 12 | FOB Price: USA $91.84 |
| METRIC STAINLESS STEEL FLAT BAR (mm) | IMPERIAL STAINLESS STEEL FLAT BAR | ||
|---|---|---|---|
| 8 X 5 | 50 X 12 mm | 3/8″ x 1/8″ | 1.1/2″ x 1/2″ |
| 12 X 3 | 50 X 20 mm | 1/2″ x 1/8″ | 1.1/2″ x 3/4″ |
| 12 X 6 | 50 X 25 mm | 1/2″ x 3/16″ | 1.1/2″ x 1″ |
| 12 X 10 | 50 X 40 mm | 1/2″ x 1/4″ | 1.3/4″ x 1.1/4″ |
| 15 X 3 | 60 X 3 mm | 5/8″ x 5/16″ | 2″ x 1/2″ |
| 15 X 5 | 60 X 5 mm | 3/4″ x 3/8″ | 2″ x 5/8″ |
| 15 X 6 | 60 X 6 mm | 1″ x 3/16″ | 2″ x 3/4″ |
| 15 X 10 | 60 X 8 mm | 1″ x 1/4″ | 2″ x 1.1/2″ |
| 16 X 8 | 60 X 10 mm | 1″ x 5/16″ | 2.1/2″ x 3/8″ |
| 20 X 3 | 60 X 12 mm | 1″ x 1/2″ | 2.1/2″ x 1″ |
| 20 X 5 | 60 X 15 mm | 1.1/4″ x 1/8″ | 2.1/2″ x 1.1/4″ |
| 20 X 6 | 65 X 5 mm | 1.1/4″ x 1/4″ | 3″ x 1/4″ |
| 20 X 8 | 65 X 6 mm | 1.1/4″ x 5/16″ | 3″ x 1/2″ |
| 20 X 10 | 65 X 8 mm | 1.1/4″ x 3/8″ | 3″ x 3/4″ |
| 20 X 12 | 65 X 10 mm | 1.1/4″ x 3/4″ | 3″ x 1″ |
| 25 X 3 | 65 X 12 mm | 1.1/4″ x 1″ | 4″ x 3/4″ |
| 25 X 4 | 65 X 15 mm | 1.1/2″ x 3/16″ | 4″ x 5/8″ |
| 25 X 5 | 70 X 10 mm | 1.1/2″ x 1/4″ | 4″ x 1″ |
| 25 X 6 | 75 X 3 mm | 1.1/2″ x 3/8″ | |
| 25 X 8 | 75 X 5 mm | ||
| 25 X 10 | 75 X 6 mm | ||
| 25 X 12 | 75 X 8 mm | ||
| 25 X 16 | 75 X 10 mm | ||
| 25 X 20 | 75 X 12 mm | ||
| 30 X 3 | 75 X 15 mm | ||
| 30 X 4 | 75 X 16 mm | ||
| 30 X 5 | 75 X 20 mm | ||
| 30 X 6 | 80 X 5 mm | ||
| 30 X 8 | 80 X 6 mm | ||
| 30 X 10 | 80 X 8 mm | ||
| 30 X 12 | 80 X 10 mm | ||
| 30 X 15 | 80 X 35 mm | ||
| 30 X 20 | 100 X 3 mm | ||
| 35 X 6 | 100 X 5 mm | ||
| 38 X 3 | 100 X 6 mm | ||
| 40 X 3 | 100 X 8 mm | ||
| 40 X 5 | 100 X 10 mm | ||
| 40 X 6 | 100 X 12 mm | ||
| 40 X 8 | 100 X 15 mm | ||
| 40 X 10 | 100 X 20 mm | ||
| 40 X 12 | 100 X 25 mm | ||
| 40 X 20 | 100 X 30 mm | ||
| 40 X 25 | 120 X 12 mm | ||
| 45 X 6 | 125 X 6 mm | ||
| 50 X 3 | 150 X 6 mm | ||
| 50 X 4 | 150 X 10 mm | ||
| 50 X 5 | 200 X 10 mm | ||
| 50 X 6 | 250 X 12 mm | ||
| 50 X 8 | 300 X 12 mm | ||
| 50 X 10 | |||
| FlatS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Stainless steel flat bars can be cut using methods like a saw (manual or power), angle grinders, laser cutting, or water jet cutting. The choice of method depends on the bar's thickness, precision required, and available equipment.
Yes, stainless steel flat bars are highly resistant to corrosion due to their chromium content, which forms a protective oxide layer. This layer prevents rust and deterioration, making stainless steel ideal for applications exposed to moisture and harsh environments.
Stainless Steel Flat Bars are widely utilized in industries where strength, corrosion resistance, and a polished appearance are crucial. They are perfect for construction frameworks, bridges, support beams, and structural reinforcements. In manufacturing, these bars are essential for creating machine parts, fasteners, tools, and base plates. The automotive and shipbuilding sectors rely on them for chassis, brackets, and marine fittings, thanks to their ability to withstand harsh weather and moisture. Additionally, they are favored in decorative applications, where both functionality and aesthetics are important.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Tariku Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Addis Ababa, Ethiopia
