Desta Steel, a prominent stainless steel manufacturer and supplier located in Addis Ababa, Ethiopia, is well-known for its dedication to quality, precision, and reliability. Among its top-notch offerings, the Stainless Steel 316L Square Bars and Rods stand out for their exceptional corrosion resistance, strength, and durability. Crafted with cutting-edge technology and rigorous quality control, these bars and rods are perfect for tough industrial, marine, and structural applications. Desta Steel guarantees outstanding dimensional accuracy, surface finish, and mechanical performance, making its 316L stainless steel products a go-to choice for customers in search of long-lasting, high-quality materials.
Stainless Steel 316L Square Bars and Rods are a type of low-carbon austenitic stainless steel made up of iron, along with 16–18% chromium, 10–14% nickel, and 2–3% molybdenum. Thanks to its lower carbon content, this material boasts excellent weldability and reduces the risk of carbide precipitation, which in turn ensures remarkable corrosion resistance, especially in environments that are chloride-rich or acidic. It has a tensile strength of about 485 MPa and a yield strength close to 170 MPa, all while offering impressive ductility, toughness, and formability. Plus, it stands out for its superior resistance to pitting and crevice corrosion, maintaining its stability and performance even in extreme temperatures, whether high or cryogenic.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 316l | 0.08 | 18.0 | 2.00 | 14.0 | 0.045 max | 3.00 max | 0.10 max |
| Element | Density, lb/in3 | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316l | 8.0 g/cm3 | 1400 °C (2550 °F) | 485 Min | 170 Min | 40% Min |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316l | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 316L Square Bars are highly corrosion-resistant, especially to pitting and crevice corrosion in chloride environments. This makes them ideal for marine and chemical applications.
Stainless Steel 316L square bars are generally non-magnetic in their annealed state. However, they may exhibit slight magnetism when cold worked.
Yes, Stainless Steel 316L square bars are suitable for heat exchangers due to their excellent corrosion resistance, high-temperature stability, and good weldability. They are ideal for applications in corrosive and high-temperature environments.
Stainless Steel 316L Square Bars and Rods from Desta Steel are widely utilized in industries that demand exceptional corrosion resistance and mechanical reliability. You’ll find them in a variety of applications, such as marine fittings, chemical processing equipment, heat exchangers, pharmaceutical machinery, and food-grade fabrication. They’re also popular in construction, architectural frameworks, and automotive components, thanks to their impressive strength and attractive finish. The square shape not only enhances load-bearing capacity but also makes machining easier for both structural and custom-engineered parts. With Desta Steel’s 316L Square Bars and Rods, you can count on durability, precision, and long-lasting performance, even in the toughest industrial and environmental conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
