Welcome to Tariku Metals, where our roots in Addis Ababa are as strong as the premium materials we supply. As a dedicated manufacturer and supplier, we take immense pride in producing Monel K500 forgings that meet the most rigorous international standards. We understand that the integrity of your project starts with the quality of its core components, which is why we are committed to delivering forgings built for durability and performance, right here from the heart of Ethiopia.
Monel K500 is a high-strength nickel-copper alloy, further enhanced by the addition of aluminum and titanium. This special composition allows it to be heat-treated, resulting in exceptional mechanical properties. The material offers a remarkable yield strength and toughness that far surpasses conventional alloys, while also maintaining excellent corrosion resistance. This unique combination of strength and durability makes it suitable for the most demanding environments.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Monel K500 Forging UNS (N05500), DIN (2.4375)
BS3072 NA18, QQ-N-286, DIN 17750, ISO 6208
AMS 4676, BS3076 NA18, ASTM B 865, DIN 17752, QQ-N-286, ISO 9723
AMS 4676, ISO 6208, ASTM B 865, DIN 17752, QQ-N-286
BS3076, NA18, DIN 17753, QQ-N-286, ISO 9724
DIN 17754, QQ-N-286, ISO 9725
UNS N05500, BS6076 NA13, Werkstoff Nr. 2.4375, MIL-N-24549, NACE MR-01-75
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 115000 , MPa – 790 | Psi – 160000 , MPa – 1100 | 20 % |
| STANDARD | UNS | WNR. |
| Monel K500 | N05500 | 2.4375 |
Temperature control during the forging of Monel K500 ensures optimal microstructure, improving strength, toughness, and corrosion resistance. It prevents defects like cracking and ensures consistent quality.
To improve the surface finish of forged Monel K500 parts, use techniques like polishing, grinding, or shot peening. Additionally, applying chemical treatments such as pickling can help remove oxides and enhance smoothness.
To determine if Monel K500 forgings meet your needs, evaluate their mechanical properties, corrosion resistance, and compliance with industry standards.
The exceptional strength and corrosion resistance of Monel K500 forgings make them indispensable in challenging environments. You will find them performing reliably in marine components like propeller shafts and pump parts, where saltwater resistance is critical. They are also essential in the oil and gas industry for tools and equipment, as well as in chemical processing for valves and fasteners. Essentially, wherever extreme stress and corrosive elements are a factor, our forgings provide a trusted, long-lasting solution.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Tariku Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Addis Ababa, Ethiopia
