Based in the heart of Addis Ababa, Tariku Metals stands as a dedicated manufacturer and supplier, bringing world-class metallurgical solutions to the region. We specialize in the production of high-performance Hastelloy forgings, engineered to meet the most demanding industrial challenges. Our commitment lies in delivering components that are not only robust and reliable but also crafted with precision, ensuring they become integral, long-lasting parts of your critical operations, supporting Ethiopia’s growing industrial landscape with trusted, locally-produced quality.
The exceptional nature of Hastelloy forgings stems from their unique composition, primarily a nickel-chromium-molybdenum alloy, which grants them a remarkable resistance to a wide range of corrosive chemicals. This is paired with outstanding mechanical properties, including high tensile strength and excellent fatigue resistance, even when subjected to extreme temperatures. The forging process itself enhances these qualities, creating a dense, uniform grain structure that results in superior toughness and reliability under immense pressure and stress.
Specifications ASTM B564 / ASME SB564
Flat bar blocks up to 27″ width and 15,000 lbs.
Cylinders and sleeves up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts up to 144″ maximum length and 20,000 lbs.
Grades Hastelloy C22, Hastelloy C276
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C 276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| C 22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| B2 | 0.02 max | 1.0 max | 0.1 max | 0.03 max | 1.0 max | Bal | 1.0 max | 2.0 max | 26 – 30 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Alloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| Alloy B2 | 9.2 g/cm3 | 1370 °C (2500 ºF ) | Psi – 1,10,000 , MPa – 760 | Psi – 51000 , MPa – 350 | 40 % |
To improve the surface finish of Hastelloy forgings, use techniques like polishing, grinding, or shot peening. Additionally, chemical or electrochemical cleaning can remove surface contaminants and enhance smoothness.
The most suitable forging techniques for Hastelloy include open-die forging and closed-die forging, which ensure optimal material flow and minimize defects. These methods provide the necessary strength and precision for high-performance applications.
To determine if Hastelloy forgings meet your needs, evaluate their chemical composition, mechanical properties, and corrosion resistance in your specific operating conditions. Conduct material testing or consult with suppliers for tailored solutions based on your application requirements.
The durability of Hastelloy forgings makes them indispensable in sectors where failure is not an option. You will find them at the core of chemical processing equipment, handling aggressive acids and catalysts, and within the powerful turbines of the aerospace industry. They are equally vital in pollution control systems, oil and gas extraction, and industrial heat treating applications, proving their worth wherever components must withstand a combination of high temperatures, intense pressure, and highly corrosive environments day after day.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Tariku Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Addis Ababa, Ethiopia
